TR DEPOT ® CUSTOMIZED FILTER HOUSING SYSTEMS
Our Customized Filter Housing Systems are engineered to meet specific filtration requirements that standard housings cannot address. Designed around your process conditions, flow rates, and filtration targets, these systems deliver optimal performance, reliability, and seamless integration into your operations.
From compact units to large-scale industrial filtration solutions, each system is developed to ensure efficiency, durability, and long-term operational stability across demanding applications.
Key Features
Fully customized design based on application requirements
Adapted to specific flow rates, pressure, and filtration levels
Compatible with bag, cartridge, or hybrid filtration systems
Robust stainless steel construction for corrosion resistance
Industrial-grade sealing system for leak-free operation
Designed for continuous and heavy-duty industrial use
Optimized internal flow distribution for maximum efficiency
Integration into existing or new process lines
Suitable for hygienic, chemical, and industrial applications
Technical Specifications
Housing Type: Single / Multi Bag / Single / Multi Cartridge / Hybrid
Material: Stainless steel (304 / 316 / special alloys on request)
Filtration Rating: 0.1 – 200 microns (depending on configuration)
Flow Capacity: Fully customizable based on process needs
Operating Pressure: up to 16 bar or higher (on request)
Operating Temperature: up to 150°C (depending on materials)
Connection Type: Flanged / Threaded / Custom
Sealing Type: O-ring / Gasket (EPDM / NBR / Viton / PTFE)
Optional Features
Differential pressure monitoring system
Automated vent and drain systems
Quick-opening or fully automated closure systems
Internal lifting systems for baskets or cartridges
Mirror polished finish for hygienic applications
Skid-mounted or modular system design
Integration with pumps, valves, and piping systems
PLC control and monitoring system
Custom dimensions and connection configurations
