FRONTLOADER SERIES
- / FrontLoader Parts Washers
TR DEPOT ® FRONTLOADER SERIES
The Frontloader Rotative Basket Parts Washer is designed for high-capacity industrial cleaning with ergonomic loading and advanced automation. Equipped with a motorized loading platform and powerful spray system, it delivers consistent and repeatable cleaning results for heavy and large components.
Key Features
Front-loading design with loading platform
Fixed basket with rotating spray arms (top and bottom)
High-capacity industrial cleaning performance
Automatic washing cycle control
Steam extraction system (standard)
Oil skimmer system (standard)
Robust and heavy-duty construction
Technical Specifications
Basket Diameter: 1160 – 1960 mm
Loading Height: 750 – 900 mm
Loading Capacity: up to 1000 kg
Number of Pumps: 2–3 pumps system
Pump Pressure: 3 – 6 bar
Heating Power: up to 40 kW
Maximum Temperature: 60–90°C
Power Supply: 380–415V / 3 Phase / 50 Hz
Optional Features
Automatic loading/unloading system
Touchscreen PLC control
Rinsing stage
Hot air drying system
Tank insulation
Advanced filtration system
