TR DEPOT ® FRONTLOADER ULTRA SERIES
The Frontloader Ultra is the most advanced solution in the range, combining automatic high-capacity washing with a powerful manual high-pressure cleaning system up to 120 bar. Designed for demanding industrial applications, it provides maximum flexibility, efficiency, and deep cleaning performance.
Key Features
Dual system: automatic washing + manual high-pressure cleaning
High-pressure pump up to 120 bar
Front-loading system with motorized platform
Multi-pump configuration for powerful spray washing
Steam extraction and oil skimmer (standard)
Ideal for complex and heavily soiled parts
Enhanced operator control and flexibility
Technical Specifications
Basket Diameter: 1160 – 1960 mm
Loading Height: 750 – 900 mm
Loading Capacity: up to 1000 kg
Spray Pump System: 2–3 pumps
Spray Pressure: 3 – 6 bar
High-Pressure Pump: up to 120 bar
Heating Power: up to 40 kW
Maximum Temperature: 60–90°C
Power Supply: 380–415V / 3 Phase / 50 Hz
Optional Features
PLC touchscreen control system
Automatic dosing system
Rinsing and drying stages
Stainless steel construction
Advanced filtration and sludge removal
Custom basket configurations
